Voltage tester UNI-T UT18D CAT IV 600V

Name: Voltage tester UNI-T UT18D CAT IV 600V
Brand: UNI-T
SKU: 40.001.0040000
Price: 72.2 EUR
Availability: InStock

SKU 40.001.0040000

In stock 13 Items

€72.20

VAT included

Functions: DC voltage, AC voltage, phase rotation, RCD test, continuity test

The UT18 series is designed to test AC/DC voltage, three-phase voltage, phase sequence, continuity and more.
This series is CAT IV 600V rated and meets the IP65 standard.
These voltage testers are perfect tools for electricians to quickly measure voltage levels in all environments.
This series should not be used with 110V electrical systems.

- RCD test (operating voltage: 230 V/50 Hz~400 Hz);
- Polarity detection: positive and negative;
- Automatic standby (standby current < 10μA);
- Silent mode;
- Integrated work light;
- Low battery indication: approx. 2.5 V

Description

Voltage ranges
6V	5V±1V
12V	8V±1V
24V	18V±2V
50V	38V±4V
120V	94V±8V
230V	180V±14V
400V	325V±15V
690V	562V±24V
Phase rotation test	57Vac～400Vac (3 phases); frequency: 50Hz~400Hz
Single-tip voltage detection	100V~690V; frequency 50Hz~400Hz
Continuity test	0Ω ~ 100kΩ (accuracy +50%); sound and light indication
RCD testing	230V (50Hz~400Hz)
Automatic polarity detection	Yes
Display	LCD, 73.5 x 35.5 mm
Stand-by current	<10μA
IP Rating	IP65
Power supply	2 AAA batteries (included)
Dimensions	272 x 85 x 31 mm
Weight	280 grams
Manufacturer	UNI-T
Model	UT18D
