| Video Compression | H.265/H.264 |
| Analogue in/out | 4CH inputs / VGA and HDMI output |
| IP Input | 2ch (IP only up to 6ch) |
| Composite video input | Up to 6ch (Analog video + IP video) |
| Audio in / out | 4CH inputs /1CH output (RCA) |
| Display | |
| Resolution | Analog: 5MP Lite/4MP Lite/3MP/1080P/720P/960H |
| IP:5MP/4MP/3MP/1080P/720P/960H | |
| Registration | |
| Resolution | Analog: 5MP Lite/4MP Lite/3MP/1080P/720P/960H |
| IP:5MP/4MP/3MP/1080P/720P/960H | |
| Speed | Analog:5MP Lite:15fps;4MP Lite:18fps; 3MP Lite:10fps; 1080P:15fps;720P:25fps; |
| IP:PAL:25fps(each ch)/NTSC:30fps(each ch) | |
| Bandwidth | 8Mbps~24Mbps |
| Maximum output bandwidth | 32Mbps |
| Maximum encoding performance | 1080P: 52fps |
| Recording mode | Continuous/Manual/Motion detection |
| Simultaneous playback | 4ch |
| Network type | LAN, DHCP, and DDNS |
| App | RXCamView |
| HDD | 1SATA HDD, up to 6TB |
| Multiplex Operations | Live view, recording, playback, backup and networking |
| USB | 2xUSB(for mouse and backup/upgrade) |
| Sensors and Alarms | 4 CH inputs /1CH output |
| PTZ support | Yes (RS485) |
| Remote surveillance | Supports iPhone and Android smartphones + Browser + VMS |
| VGA / HDMI | 1024*768,1280*1024,1440*900,1920*1080,2560*1440(2K),3840*2160(4K) |
| Power supply | 12Vdc 2A |
| Dimensions | 300 x 227 x 53 mm |
| Model | 5MP 4CH+ |
| Manufacturer | MKC TRUEVISION |
