Solid-state relay, low profile, 12Vdc, SPST-NO, 3 A, switching voltage 240Vac, series 41.81 - Finder 41.81.7.012.8240

Name: Solid-state relay, low profile, 12Vdc, SPST-NO, 3 A, switching voltage 240Vac, series 41.81 - Finder 41.81.7.012.8240
Brand: Finder
SKU: 52.130.7103002
Price: 32.2 EUR
Availability: InStock

SKU 52.130.7103002

In stock 12 Items

€32.20

Tax included

Solid State Relay (SSR) for PCB or socket mounting 93 series.
Low noise, high switching speed and long electrical life.
Suitable for PCB mounting.

Features:
- PCB mounting (direct or on PCB sockets) or 35 mm rail mounting (EN 60715) on sockets with sleeve or spring terminals;
- Single output circuit 3 A, 240 V AC;
- Low noise, high switching speed and electrical life;
- Low profile (15.7 mm);
- Washable: RT III;
- Input-to-output isolation 2500 V AC.

Description

Output circuit
Contact configuration	1 NO contact
Rated current/maximum instantaneous current	3A / 40A
Rated switching voltage	240 Vac
Switching voltage	12 ~ 275 Vac
Maximum blocking voltage	240 Vac
Minimum switching current	50 mA
Maximum output drop-out voltage ON	1,1 V
Input circuit
Supply voltage	12 Vdc
Operating range	8 ~ 17 Vdc
Nominal absorption	8.8 mA
Release voltage	4 Vdc
General features
Tripping time: ON/OFF	10 mS
Dielectric strength between input/output	2500 Vac
Operating temperature	-20°C ~ +60°C
Protection category	RTIII
Product information
Model	41.81.7.012.8240
Manufacturer	Finder
