Fuse NH 2 M58 aR 170 series, super fast, with striker, 690V 700A - Wimex 5523713

Fuse NH 2 M58 aR 170 series, super fast, with striker, 690V 700A - Wimex 5523713

Name: Fuse NH 2 M58 aR 170 series, super fast, with striker, 690V 700A - Wimex 5523713
Brand: Wimex
SKU: 61.001.2205913
Price: 175.5 EUR
Availability: InStock

SKU 61.001.2205913

In stock 2 Items

Last items in stock

€175.50

Tax included

NH super-rapid industrial fuses, characterised by high breaking capacity and low specific energy throughput (I²t), are manufactured with blade and bolt fixing, both with aR (short-circuit protection) and gR (full short-circuit and overload protection) characteristics.
Reference standards: IEC 32.1-.7,IEC EN 60269.1-.4, DIN 43620, VDE 0636.

Description

Rated voltage	690 Vac (IEC); 700 Vac (UL)
Interrupting power (lk)	690 Vac 200 KA (IEC); 700Vac 200 KA (UL)
Material	Steatite
Intervention characteristic	Super fast
Interruption range	AR
I²t	430000
Pw	43
Reference Standards	CEI 32.1-.7,IEC EN 60269.1-.4, DIN 43653
Model	55237013
Manufacturer	Wimex
