| Number of conductors | 5 |
| Conductor material | Flexible annealed red copper rope, class 5 |
| Insulation | TI2 quality PVC compound |
| Outer sheath | TM2 quality PVC compound |
| Rated voltage | 300/500V |
| Maximum operating temperature: | 60°C |
| Minimum installation temperature: | 5°C |
| Maximum short-circuit temperature: | 150°C |
| Maximum tractive effort: | 15 N/mm2 |
| Colour of outer sheath | Black |
| Conductor diameter | 1.3 mm |
| Average insulation thickness | 0.6 mm |
| Average sheath thickness | 0.9 mm |
| Outer diameter | 9.8 mm |
| Regulations | CPR (EU) No. 305/11, EN 50525-2-11 - IEC 20-107/2-11, 2014/35/EU, 2011/65/EC |
| Manufacturer | According to stock availability. Main suppliers: La Triveneta, Prysmian, Baldassarri Cavi. |
